Dual Band AC1750 Gigabit ADSL2+ Modem Router User Manual
Product Overview Page 6
Rear Panel
Number Description
ADSL Port - Use the DSL cable to connect to your telephone line (RJ-11 port).
USB (3.0) Port - Use the USB 3.0 port to connect your USB 3.0 device.
USB (2.0) Port - Use the USB 2.0 port to connect your USB 2.0 device.
Ethernet Ports - Use the Ethernet ports to connect the router to your Ethernet
LAN or Ethernet devices.
Wireless On/Off Switch Button - Please press and hold on for 3 seconds to
turn on/turn off.
Power Button - Push in to power-on the router. Push again to power-off the
router.
Power Receptor - Receptor for the supplied power adapter.
