D-Link DSL-3782 User Manual

11D-Link DSL-3782 User Manual
Section 2 - Installation
Connect the supplied power adapter to the modem router and a power outlet, and press the power button. The
device LEDs will light up. Wait approximately three minutes before moving on to step 4.
Caution: Use only the included power adapter with this product.
Plug one end of the supplied Ethernet cable into a yellow Ethernet port on the back of the modem router, and the
other end into the Ethernet port on your computer.
If you are setting up the DSL-3782 using a laptop or mobile device, connect to it using the Wi-Fi network name
and password printed on the label attached to the back of your router.
3
4
DSL-3782
Power
PC
DSL-3782
Power
PC
PC
Phone
Phone

D-Link DSL-3782 Specifications

General

LED indicators	DSL, LAN, Power, WAN
DC-in jack	Yes
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	4
Certification	CE DLNA Wi-Fi Certified LVD BT OpenReach SIN498
USB connector type	Micro-USB
Security algorithms	WPA, WPA2
Antenna type	Internal
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Package depth	262 mm
Package width	155 mm
Package height	77 mm
Package weight	430 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1847 mm
Pallet gross weight (air)	384260 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	278 mm
Shipping (inner) case height	403 mm
Shipping (inner) case length	327 mm
Shipping (inner) case weight	7620 g
Shipping (inner) case net weight	4300 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	30.75 mm
Width	210 mm
Height	150 mm
Weight	113.05 g
Dimensions (WxDxH)	210 x 150 x 30.75 mm
