5D-Link DSL-3782 User Manual
Section 1 - Product Overview
Hardware Overview
Back Panel
1 Power Connector Connector for the supplied power adapter.
2 USB 2.0 Port Connects to USB ash drives to share content.
3 LAN Ports (1-4)
Connects to Ethernet devices such as computers, switches, storage (NAS) devices and
game consoles.
4 Reset Button
To reset the device to its factory default settings, use a paper clip to press and hold the
reset button for 5 seconds.
5 DSL Port Connects to an DSL-enabled telephone line.
1 4 532
