Section 3 - Getting Started
Setup Wizard
If this is your rst time using the router, open your web browser and enter
http://dlinkrouter.local./ in the address bar. Alternatively, enter the IP address
of the router (default: http://192.168.1.1). The default password is admin.
The wizard is designed to guide you through a step-by-step process to congure
your new D-Link router and connect to the Internet. Ensure that your DSL phone
cable is connected to both the router and the wall jack.
Click Next to continue.
First, you must select your WAN Access Type. The options are ADSL, VDSL, or
Auto. To quickly nd your ISP's settings, select your Country and ISP. The VPI
and VCI values will automatically be congured.
Click Next to continue.

D-Link DSL-3782 Specifications

General

LED indicators	DSL, LAN, Power, WAN
DC-in jack	Yes
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	4
Certification	CE DLNA Wi-Fi Certified LVD BT OpenReach SIN498
USB connector type	Micro-USB
Security algorithms	WPA, WPA2
Antenna type	Internal
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Package depth	262 mm
Package width	155 mm
Package height	77 mm
Package weight	430 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1847 mm
Pallet gross weight (air)	384260 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	278 mm
Shipping (inner) case height	403 mm
Shipping (inner) case length	327 mm
Shipping (inner) case weight	7620 g
Shipping (inner) case net weight	4300 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	30.75 mm
Width	210 mm
Height	150 mm
Weight	113.05 g
Dimensions (WxDxH)	210 x 150 x 30.75 mm
