D-Link DSL-3782 User Manual

50D-Link DSL-3782 User Manual
Section 4 - Conguration
ACL
The Access Control List (ACL) page allows you to enable or disable various
services from being used on the LAN or WAN side. To access this page, click
ACL from the Features menu on the bar on the top of the page.
Access Control Setup
ACL: Activate or deactivate ACLs.
ACL Rule Index: Select the ACL rule index number from the drop down menu.
Active: Activate or deactivate the individual ACL rule.
Service IP address: Enter the IP address range to apply the rule to.
Application: Select a pre-dened service.
ACL Rule
IndexInterface:
Select the interface from the drop down menu to apply this access
control list rule to.
Click Set to create or modify a rule or Delete to remove a rule.
Access Control Listing
A list of the currently dened Access Control List rules is displayed here.

D-Link DSL-3782 Specifications

General

LED indicators	DSL, LAN, Power, WAN
DC-in jack	Yes
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	4
Certification	CE DLNA Wi-Fi Certified LVD BT OpenReach SIN498
USB connector type	Micro-USB
Security algorithms	WPA, WPA2
Antenna type	Internal
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Package depth	262 mm
Package width	155 mm
Package height	77 mm
Package weight	430 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1847 mm
Pallet gross weight (air)	384260 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	278 mm
Shipping (inner) case height	403 mm
Shipping (inner) case length	327 mm
Shipping (inner) case weight	7620 g
Shipping (inner) case net weight	4300 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	30.75 mm
Width	210 mm
Height	150 mm
Weight	113.05 g
Dimensions (WxDxH)	210 x 150 x 30.75 mm
