21D-Link DSL-3782 User Manual

Section 4 - Conguration

IPv4

DSL Type: Displays the current DSL type, either ADSL or VDSL.

Cable Status: Displays the current cable connection status.

Link Rate: Displays the currently negotiated connection speed.

Connection Type: Displays the network protocol used to obtain an IP address.

Network Status: Displays the current network connection status.

Connection

Uptime:

Displays the amount of time the connection has been connected.

MAC Address: Displays the MAC address of this interface.

IP Address: Displays the current WAN IPv4 address.

Subnet Mask: Displays the current subnet mask.

Default Gateway: Displays the current IPv4 default gateway.

Primary DNS

Server:

Displays the current primary DNS server.

Secondary DNS

Server:

Displays the current secondary DNS server.

IPv4

Click the IPv4 button to see the IPv4 information for the DSL interface. If you

have congured your ADSL/VDSL connection to use PPPoE with On-Demand

or Manual settings, you can connect to or disconnect from the Internet by

pressing the Connect or Disconnect buttons.

Other manuals for D-Link DSL-3782

Need help?

Do you have a question about the D-Link DSL-3782 and is the answer not in the manual?

General

LED indicators	DSL, LAN, Power, WAN
DC-in jack	Yes
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	4
Certification	CE DLNA Wi-Fi Certified LVD BT OpenReach SIN498
USB connector type	Micro-USB
Security algorithms	WPA, WPA2
Antenna type	Internal
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Package depth	262 mm
Package width	155 mm
Package height	77 mm
Package weight	430 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1847 mm
Pallet gross weight (air)	384260 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	278 mm
Shipping (inner) case height	403 mm
Shipping (inner) case length	327 mm
Shipping (inner) case weight	7620 g
Shipping (inner) case net weight	4300 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)
