D-Link DSL-3782 User Manual

14D-Link DSL-3782 User Manual
Section 3 - Getting Started
If the router cannot determine your connection type, a list of connection types
to choose from will be displayed. Select your Internet connection type (this
information can be obtained from your Internet Service Provider) and click
Next to continue.
If the router detected or you selected PPPoE, enter your PPPoE username and
password, choose the Connection Type if asked, and click Next to continue.
Note: Make sure to remove your PPPoE software from your computer. The software
is no longer needed and will not work through a router.
Setup Wizard (continued)

D-Link DSL-3782 Specifications

General

LED indicators	DSL, LAN, Power, WAN
DC-in jack	Yes
Modem (RJ-11) ports	1
Ethernet LAN (RJ-45) ports	4
Certification	CE DLNA Wi-Fi Certified LVD BT OpenReach SIN498
USB connector type	Micro-USB
Security algorithms	WPA, WPA2
Antenna type	Internal
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	10 - 95 %
Package depth	262 mm
Package width	155 mm
Package height	77 mm
Package weight	430 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1847 mm
Pallet gross weight (air)	384260 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	278 mm
Shipping (inner) case height	403 mm
Shipping (inner) case length	327 mm
Shipping (inner) case weight	7620 g
Shipping (inner) case net weight	4300 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	10 pc(s)

Weight and Dimensions

Depth	30.75 mm
Width	210 mm
Height	150 mm
Weight	113.05 g
Dimensions (WxDxH)	210 x 150 x 30.75 mm
