DSL-524B User Manual
5 Total 15 Pages
3. CONFIGURATION
3.1 DEFAULT CONFIGURATION
ADSL MODEM has pre-configured with the VCI/VPI which is in common use. The default dial-up
mode is bridge encapsulation. For bridge mode, no need to configure any more parameter. However,
the third party dial-up software is needed for connection with the Internet.
3.2 COMPUTER CONFIGURATION
The default IP address for ADSL MODEM is: 10.1.1.1; The Subnet Mask is：255.0.0.0. Users can
configure ADSL MODEM through an Internet browser. ADSL Modem can be used as gateway and
DNS server; users need to set the computer’s TCP/IP protocol as follow:
1、 Set the computer IP address at same segment of ADSL Modem, such as set the IP address of
the network card to one of the “10.1.1.2”～ “10.1.1.254”.
2、 Set the computer’s gateway the same IP address as the ADSL Modem’s.
3、 Set computer’s DNS server the same as ADSL Modem’s IP address or that of an effective
DNS server.
3.3 ADSL MODEM CONFIGURATION
3.3.1 LOG IN
Open the browser; input http://10.1.1.1 at the address column. Press “Enter” key then the entry
dialog box will show up as Figure 3.1. Input Username: admin , Password: admin (capital sensitive),
then press Enter.
Figure 3.1
