DSL-524B User Manual
8 Total 15 Pages
The Modem supports five ADSL protocol modes. Choose the protocol which is appointed by ISP
and
PVC encapsulation, click “Next” enter to the protocol configure. Below, we introduce the
configuratio
ns of the five protocol modes.
• PPP over ATM (PPPoA) • PPP over Ethernet (PPPoE)
• MAC Encapsulated Routing (MER) • IP over ATM (IPoA)
• Bridging
Some connection lines need to confirm the LLC or VC, if you can’t confirm, please don’t modify
the
default value or ask your ISP.
3.4.2 RFC1483 BRIDGE CONFIGURATION
Select the Bridging mode. Then press “Next” to specify the Service Name, and select the “Enable
Service”
as Figure 3.5.
Figure
3.5
Press
“Next” to enter into “WAN configuration”, click “save” to save configuration, if you need to
modify
the parameter, click “back” as Figure 3.6.
