2.2 Hardware Structure
Here, we take DVX-2004G as the sample to show the interface and the indicators at the
front and back panel.
2.2.1 Back Panel
 4 GSM Antennas
 2 Network Interface (RJ45)
 1 Power Interface (DC 12V 2A)
 1 Reboot Button
2.2.2 Front Panel
Mark Function Status Description
On Power On
PWR Power Status
Off Power Off
On System working
SYS System Status
Off System Failed
