6
Wink Data exchanging
WAN WAN interface Status
Off No Data exchanging
Wink Data exchanging
LAN LAN Interface Status
Off No Data exchanging
Red GSM channel
G1~G4 GSM Modules Status
Off Failed
Green FXS channels
Red FXO channels
*1-4 Analog Modules Status
Off Failed
2.2.3 Hardware:
32bit embedded RISC DSP
1G Onboard Nand Flash
128M Onboard SDRAM
2.2.4 Environmental Requirements:
temperature: -10 °C -45 °C
Storage temperature: -30 °C -65 °C
humidity: 10-80% no dew
Power: AC 100~240V
2.2.5 Packing List
DVX-2004 IP PBX 1 Unit
Power Adapter 1 Unit
Quick Start Guide 1 Piece
CD 1 Piece
Product Maintenance Card 1 Piece
Antenna(Only for DVX-2004G) 4 Piece
