D-Link DWA-110 Quick Install Guide

9 D-Link DWA-110 Quick Install Guide
Hold the USB adapter with both hands.
Apply little force to slowly pull out the cover
from both sides.
Insert the DWA-110 into an available
USB port on your computer.
Optional: If desired or necessary, attach
the cradle between the DWA-110 and
your computer.
USB Installation

D-Link DWA-110 Specifications

General

Wi-Fi	Yes
Modulation	DBPSK
Wi-Fi band	Single-band (2.4 GHz)
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2-PSK
Maximum data transfer rate	54 Mbit/s
Connectivity technology	Wireless
Output voltage	5 V
RX power consumption	280 mA
Dimensions (WxDxH)	87 x 28 x 12 mm
Compliance industry standards	IEEE 802.11g/b
Compatible operating systems	Windows 98SE, ME, XP SP2, 2000 SP4, Vista
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, Wi-Fi, WPS
