D-Link DWA-192 Quick Install Guide

Product Overview
USB 3.0 Connector
LED Ring
WPS Button
LED On/O
Button
LED Ring
A solid blue light indicates a proper connection to a
wireless network. This LED will blink if it is not connected
to a wireless network.
LED On/O
Button
Press to turn the LED on or o.
USB 3.0
Connector
Connect the supplied USB 3.0 cable here and the other
end to your computer.
WPS Button
Press to start the WPS process. You will need to press
the WPS button on your wireless router within two
minutes. The light will turn solid blue when successfully
connected.
3

D-Link DWA-192 Specifications

Operating Environment

operating temperature	0 °C to 40 °C
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4 GHz to 2.4835 GHz, 5.150 GHz to 5.850 GHz

Power

operating voltage	5 V DC +/- 10%
current consumption	880 mA

Weight and Dimensions

weight	167 grams
dimensions	79.92 x 79.92 x 77 mm
