D-Link DWA-192 User Manual

4D-Link DWA-192 User Manual
Section 1 - Product Overview
Hardware Overview
1 Status LED
Blinking blue: The device is connected to the computer. Solid blue: The device is connected to
the network.
2 LED On/O Button Turns the Status LED on or o.
3 Micro USB 3.0 Connector Used to connect the DWA-192 to your computer via the included cable.
4 WPS Button
Press the WPS button to automatically connect to a WPS-enabled wireless router or access point
and establish connectivity.
32 4
1

D-Link DWA-192 Specifications

Operating Environment

operating temperature	0 °C to 40 °C
operating humidity	10% to 90% maximum (non-condensing)
frequency range	2.4 GHz to 2.4835 GHz, 5.150 GHz to 5.850 GHz

Power

operating voltage	5 V DC +/- 10%
current consumption	880 mA

Weight and Dimensions

weight	167 grams
dimensions	79.92 x 79.92 x 77 mm
