Quick Installation Guide
DWM-156
3.75G HSUPA USB ADAPTER
About D-Link 3.75G HSUPA USB Adapter
Hardware Installation
The 3.75G HSUPA USB Adapter allows user with a computer to connect to worldwide
mobile broadband networks (GPRS/EDGE/UMTS/HSPA). While connected, users can
access the Internet, transfer data, stream media, and send SMS messages.
SIM Card Installation Steps:
Remove the cover from the end of the adapter. 1.
Pull out the SIM card tray. 2.
Insert the SIM card with the gold contacts 3.
facing down.
Push the SIM card tray back into the adapter. 4.
Connect the adapter to a USB port on your 5.
computer.
Note: To remove an installed SIM card, pull out
the SIM card tray and gently lift the card.
MicroSD Card Installation Steps (optional):
Gently lift the upper left corner of the MicroSD 1.
card slot cover.
Insert the MicroSD card with the gold contacts 2.
facing upwards.
Replace the MicroSD card slot cover.3.
Note: To remove a MicroSD card, unplug the
device from the computer. Open the card slot
cover and gently push the card in to release it.

D-Link DWM-156 Specifications

GSM and UMTS Specifications

GSM Band	850, 900, 1800, 1900 MHz
UMTS/HSDPA Band	850/1900/2100 MHz
Power Class 4	900 / 1850 MHz

Data Rates

Download Speed	7.2 Mbps (HSDPA)
Upload Speed	5.76 Mbps (HSUPA)
Power Class 3	+24 dBm

Dimensions and Operating Environment

Dimensions	86.75 x 28 x 11.4 mm
Operating Temperature	-10˚ to 55˚C (14˚ to 131˚F)
Supported MicroSD Card Capacity	up to 8GB
