D-Link DWM-156 Quick Installation Guide

2
3
Software Installation
Troubleshooting
1. Where can I nd more information about how to use this device?
A comprehensive User Manual is available for the DWM-156. Open the D-Link
Mobile Connection manager and click: Support > Help. The manual requires
Acrobat Reader.
2. Why am I unable to connect to a mobile service network?
The DWM-156 requires a SIM card registered with a compatible service
network. For information about the services that your SIM card provides access
to, please contact your mobile service provider.
3. Why is the software asking for a PIN number?
For security, some SIM cards have a PIN number enabled. If the SIM was used
in a previous device, the PIN will be the same as it was before. If you did not
set a PIN, please contact your mobile service provider.
Technical Support:
Thank you for choosing D-Link products. For further information, technical support,
product drivers, and manuals, please visit the D-Link website.
Before you install the software, you must rst install a SIM card into the USB
adapter and connect the adapter to a USB port on your computer.
Open 1. My Computer.
Double click on the drive labeled 2. ConnMgr.
Double click the le labeled “3. setup.exe” to start the installation.
Follow the step-by-step instructions on the Installation Wizard. The software will 4.
take about 30 seconds to install.
The D-Link Mobile Connection Manager will launch automatically.5.

D-Link DWM-156 Specifications

GSM and UMTS Specifications

GSM Band	850, 900, 1800, 1900 MHz
UMTS/HSDPA Band	850/1900/2100 MHz
Power Class 4	900 / 1850 MHz

Data Rates

Download Speed	7.2 Mbps (HSDPA)
Upload Speed	5.76 Mbps (HSUPA)
Power Class 3	+24 dBm

Dimensions and Operating Environment

Dimensions	86.75 x 28 x 11.4 mm
Operating Temperature	-10˚ to 55˚C (14˚ to 131˚F)
Supported MicroSD Card Capacity	up to 8GB
