DES-3526 / DES-3526DC Layer 2 Fast Ethernet Switch CLI Reference Manual
147
create access_profile
Purpose Used to create an access profile on the Switch and to define which parts of each incoming frame’s
header the Switch will examine. Masks can be entered that will be combined with the values the
Switch finds in the specified frame header fields. Specific values for the rules are entered using
the config access_profile command, below.
Syntax
create access_profile [ethernet {vlan | source_mac <macmask> |
destination_mac <macmask> | 802.1p | ethernet_type} | ip {vlan |
source_ip_mask <netmask> | destination_ip_mask <netmask> | dscp | [icmp {type | code} |
igmp {type} | tcp {src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff> |
flag_mask [all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex 0x0 - 0xFF>
{user_define_mask <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff>}]} | packet_content_mask {offset_0-15
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> |
offset_16-31 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> |
offset_32-47 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> |
offset_48-63 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> |
offset_64-79 <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> }
] [profile_id <value 1-255>]
Description The create access_profile command is used to create an access profile on the Switch and to
define which parts of each incoming frame’s header the Switch will examine. Masks can be
entered that will be combined with the values the Switch finds in the specified frame header fields.
Specific values for the rules are entered using the config access_profile command, below.
ethernet − Specifies that the Switch will examine the layer 2 part of each packet header.
• vlan − Specifies that the Switch will examine the VLAN part of each packet header.
• source_mac <macmask> − Specifies a MAC address mask for the source MAC address.
This mask is entered in a hexadecimal format.
• destination_mac <macmask> − Specifies a MAC address mask for the destination MAC
address.
• 802.1p − Specifies that the Switch will examine the 802.1p priority value in the frame’s
header.
• ethernet_type − Specifies that the Switch will examine the Ethernet type value in each
frame’s header.
