DES-3526 / DES-3526DC Layer 2 Fast Ethernet Switch CLI Reference Manual
219
Physical and Environmental
Internal power supply
DES-3526 AC Input: 100 – 120; 200 – 240 VAC, 50/60 Hz
DES-3526 DC 60W DC Power Input: 48 V
Output: 12V
Power Consumption
23 watts maximum
DC fans:
one 40 mm fan
Operating Temperature
0 - 40°C
Storage Temperature
-40 - 70°C
Humidity
5 - 95% non-condensing
Dimensions
441 mm 207 mm 44 mm (1U), 19 inch rack-mount width
Weight
DES-3526 2.56 kg / DES-3526DC 2.5 kg
EMI
CE class A, FCC Class A, C-Tick, VCCI Class A
Safety
CSA International
Performance
Transmission Method
Store-and-forward
Packet Buffer
16 MB per device
Packet Filtering / Forwarding
Rate
Full-wire speed for all connections. 1,488,095 pps per port (for
1000Mbps)
MAC Address Learning
Automatic update. Supports 8K MAC address.
Priority Queues
4 Priority Queues per port.
Forwarding Table Age Time
Max age: 10-1000000 seconds. Default = 300.
