DES-3526 / DES-3526DC Layer 2 Fast Ethernet Switch CLI Reference Manual
165
clear arptable
Purpose Used to remove all dynamic ARP table entries.
Syntax
clear arptable
Description This command is used to remove dynamic ARP table entries from
the Switch’s ARP table. Static ARP table entries are not affected.
Parameters None.
Restrictions Only administrator-level users can issue this command.
Example Usage:
To remove dynamic entries in the ARP table:
DES-3526:4#clear arptable
Command: clear arptable
Success.
DES-3526:4#
