different inputs, the system will show F3 when at least one function is
activated. The alarm is removed when no input is activated
Behaviour of the system enabling and fault reset function depending on Ix
and on the input
Value of
Parameter
Ix
,QSXWFRQ¿JX-
ration
Input status Operation
Shown on
display
5
Active with high
signal on input
(NO)
Absent Motor enabled None
Present Motor disabled F3
6
Active with low
signal on input
(NC)
Absent Motor disabled F3
Present Motor enabled None
7
Active with high
signal on input
(NO)
Absent Motor enabled None
Present
Motor disabled +
reset blocks
F3
8
Active with low
signal on input
(NC)
Absent
Motor disabled +
reset blocks
F3
Present Motor enabled None
9
Active with high
signal on input
(NO)
Absent Motor enabled None
Present Reset blocks None
7.7.8.5 - Setting low pressure detection (KIWA)
The minimum pressure switch that detects low pressure can be con-
nected to any input (for the electrical connections see paragraph Input
connections (photocoupled).
The low pressure detecting function is obtained, setting one of the values
in Table 16 on the parameter INx, for the input to which the enabling
Table 18: Abilitazione sistema e ripristino dei fault
Behaviour of the auxiliary setpoint function depending on Ix and on the
input
Value of Para-
meter
Ix
,QSXWFRQ¿JX-
ration
Input status Operation
Shown on
display
3
Active with high
signal on input
(NO)
Absent
i-th auxiliary
setpoint not active
None
Present
i-th auxiliary
setpoint active
Px
4
Active with low
signal on input
(NC)
Absent
i-th auxiliary
setpoint active
Px
Present
i-th auxiliary
setpoint not active
None
7.7.8.4 - Setting system enabling and fault reset
The signal that enables the system can be supplied to any input (for the
electrical connections see paragraph connections (photocoupled)
The enabling function is obtained, setting one of the values in Table 15
on the parameter Ix, for the input to which the enabling signal has been
connected.
When the function is active the system is completely disabled and F3 is
shown on the STATUS line of the main page.
:KHQVHYHUDOV\VWHPGLVDEOLQJIXQFWLRQVDUHFRQ¿JXUHGDWWKHVDPHWLPH
on different inputs, the system will indicate F3 when at least one function
is activated and will remove the alarm when none is activated.
For the system to work with the disable function, the input must be active
for at least 1 sec.
When the system is disabled, for the function to be deactivated (re-
enabling the system), the input must not be active for at least 1 sec. The
behaviour of the function is summed up in Table 15.
:KHQVHYHUDOGLVDEOHIXQFWLRQVDUHFRQ¿JXUHGDWWKHVDPHWLPHRQ
Table 17: Auxiliary setpoint
