12
Attivo con
segnale alto
sull’ingresso
(NO)
Absent Normal None
Present
Block of system
for low pressure
on intake.
Manual reset
F4
13
Attivo con
segnale basso
sull’ingresso
(NC)
Absent
Block of system
for low pressure
on intake.
Manual reset
F4
Present Normal None
7.8 - Setup of the outputs OUT1, OUT2
7KLVSDUDJUDSKVKRZVWKHIXQFWLRQVDQGSRVVLEOHFRQ¿JXUDWLRQVRIWKH
inputs OUT1 and OUT2 of the I/O control unit, connected by wireless to
the device, by means of the parameters O1 and O2.
For the electrical connections see par. Output connections OUT1 and
2877KHIDFWRU\FRQ¿JXUDWLRQVFDQEHVHHQLQ7DEOH
)DFWRU\FRQ¿JXUDWLRQVRIWKHRXWSXWV
Uscita Value
OUT 1 2 (fault NO closes)
OUT 2 2 (Pump running NO closes)
7.8.1 - O1: Setting output 1 function
Output 1 communicates an active alarm (it indicates that a system block has
occurred). The output allows the use of a normally open clean contact.
The values and functions indicated in Table 18 are associated with the param-
eter O1.
Table 19: Detecting the low pressure signal (KIWA)
7DEOH)DFWRU\FRQ¿JXUDWLRQVRIWKHRXWSXWV
signal has been connected.
The activation of the low pressure detecting function generates the block-
ing of the system after the time T1 (see par. 7.6.2 - T1: Low pressure
delay (kiwa function)). The function has been conceived to connect the
input to the signal arriving from a pressure switch which indicates too low
a pressure on the pump intake.
When this function is active the symbol F4 is shown on the STATUS line
of the main page.
When it is in error condition F4, the input must have been deactivated for
at least 2 sec before the system can be unblocked. The behaviour of the
function is summed up in Table 16.
:KHQORZSUHVVXUHGHWHFWLRQIXQFWLRQVDUHFRQ¿JXUHGDWWKHVDPHWLPH
on different inputs, the system will indicate F4 when at least one function
is activated and will remove the alarm when none is activated.
Behaviour of the system enabling and fault reset function depending on Ix and on
the input
Value of Para-
meter
Ix
,QSXWFRQ¿JX-
ration
Input status Operation Shown on display
10
Active with high
signal on input
(NO)
Absent Normal None
Present
Block of system
for low pressure
on intake, Auto-
matic + Manual
reset
F4
11
Active with low
signal on input
(NC)
Absent
Block of system
for low pressure
on intake, Auto-
matic + Manual
reset
F4
Present Normal None
