dacell DN-10W User Manual

27
F-30. DAC mode (Setting Analog output type)
① DN-10W, DN-25W, DN-27W, DN-50W, DN-70,80
(Standard setup value : b_10V)
Display data Setting
b_05v -5 ~ +5V output
bidirectional, polarity
b_10v -10 ~ +10V output
b_02A 0 ~ 20mA output
unidirectional, unipolar
b_42A 4 ~ 20mA output
U_05v 0 ~ 5V output
bidirectional, unipolar
U_10v 0 ~ 10V output
U_02A 0 ~ 20mA output
U_42A 4 ~ 20mA output
② DN-20W, DN-30W
(Standard setup value : b_10V)
Display data Setting
b_05v 0 ~ 5V 출력
unidirectional, unipolar
b_10v 0 ~ 10V 출력
b_02A 0 ~ 20mA 출력
b_42A 4 ~ 20mA 출력
U_05v 0 ~ 5V 출력
bidirectional, unipolar
U_10v 0 ~ 10V 출력
U_02A 0 ~ 20mA 출력
U_42A 4 ~ 20mA 출력
F-31. DAC capacity (Analog Outupt value setup)
(Standard setup value : 30000)
Display data Setting
0 Set the rated capacity of the Analog output
< If Setting value 10000>
Display
data
F-30 setting data
b_05v
b_10v b_02A b_42A U_05v U_10v U_02A U_42A
-10000 -5V -10V 0 4mA 0 0 0 4mA
0
0 0 0 4mA 2.5V 5V 10mA 12mA
10000
+5V +10V 20mA 20mA 5V 10V 20mA 20mA
~
+99999
Note) Models DN-20W and DN-30W cannot be negative (-) output.
