● Check areas which caused for concern
when last operating the vehicle.
● If happened, contact authorized
maintenance shops for necessary
inspection and repairs.
<BRAKE LEVER FREE PLAY>
Lightly squeeze the brake levers until
tension is felt to check for an appropriate
amount of free play. No free play in the
brake levers or overly loose brake levers
are indication of a problem in the brake
system.
BRAKE LEVER FREE PLAY: 10-20mm
<CHECK OF BRAKE FLUID>
This is checked by placing the vehicle on
its main stand on a flat surface. Make sure
that the handle bars are at a horizontal
level. Check to see if the fluid are below
the LOWER level.
If brake fluid are significantly low, this
may indicate that there are leakage in the
brake system. Inspect the brake hoses to
check for leaks.
26
BRAKE INSPECTION
LOWER LEVEL
FREE PLAYFREE PLAY
CAUTION
●Specified brake lever free play
must be maintained. Excessive free
play may cause long stopping
distance, brake operational fault
and slow reacting time resulting in
the dangerous situation and
insufficient free play may cause
short stopping distance and damage
brake system(pad, lining, etc.)
CAUTION
●If the brake fluid is significantly
lower than the specified level,
inspect not only brake fluid but also
check the front brake pad for wear.
INSPECTION OF CONCERNED AREA
