Daewoo Bus BS106 - Seat Depth Adjustment; Vertical Shock Absorber Adjustment

Seat Depth Adjustment
To adjust the depth of the seat cushion,
pull the right handle upwards. By
moving the seat cushion, backwards or
forwards the desired seating position
can be reached.
Height Adjustment
Pull or press the handle for height
adjustment to move the seat upwards
or downwards.
Vertical Shock Absorber Adjustment
The vertical vibration behavior of the
seat can be adjusted continuously from
soft to hard by using the turning knob.
1 = Soft shock absorption
2 = Medium shock absorption
3 = Hard shock absorption
3 - 15
DEVICE CONTROL TIPS
OM-F024 OM-F025 OM-F163
REFERENCE
Adjustable within a range of 60 mm
in 6 steps.
REFERENCE
The seat height can be adjusted
continuously within a range of 100
mm.
Always release the handle after
reaching the upper or lower stop.
·
·
