Press the button on the tip of the lever
to spray washer fluid onto the
windshield. Single operation of the
switch automatically activates the
wipers 2~3 times.
When the switch is pushed, the parking
brake is actuated and the indicator
lamp comes on. Pushed one more the
switch, release the brake. Make sure
that the indicator lamp is off before
driving off.
Pull the parking brake application
valve’s lever and fix the lever using
the LOCK button to have the vehicle in
a parked state. The parking indicator
lamp turns on in the instrument panel
when the key switch in the “ON”
position.
Pull the parking brake application
valve’s LOCK button up and push it
together with the lever to release the
parking brake.
3
-
39
DEVICE CONTROL TIPS
Washer Fluid Switch Parking Brake
OM-B116 OM-B546 OM-B117E
TYPE A TYPE B
