Air Pressure (Subsidiary, Suspension) Warning Lamp
The lamp turns on when the air pressure drops below about
5.3 kgf/cm
2
, indicating that the subsidiary and suspension
system air tanks have insufficient air.
Air Tank (Front Wheel) Air Pressure Warning Lamp
The lamp turns on when the air pressure
falls below 5.3 kgf/cm
2
due to insufficient
air in the front wheel brake tank.
Air Tank (Rear Wheel) Air Pressure Warning Lamp
The lamp turns on when the air pressure
falls below 5.3 kgf/cm
2
due to insufficient
air in the rear wheel brake tank.
Air Tank (Parking Brake) Air Pressure Warning Lamp
The lamp turns on when the air pressure falls below 6.2
kgf/cm
2
due to insufficient air in the parking brake tank, while
the lamp flickers when the air pressure falls below 4.2 kgf/cm
2
.
3
-
28
DEVICE CONTROL TIPS
OM-B372
OM-B369
OM-B370
OM-B524E OM-B371 OM-B525
WARNING
Operate the vehicle with recommended safe distance to
other vehicles, since frequent application of the brake
results in a sudden drop in the air pressure.
REFERENCE
Parking brake is applied using the spring power of the
spring power of the spring brake chamber, and only
applies to the rear wheels.
TYPE A TYPE B TYPE A TYPE B
