The controls are used to activate the
interior heater.
① Rotary Switch
It is used to adjust wind power by
steps.
② Button Switchs
It is used for activating the passenger
area heater and to turn ON/OFF the
main power.
The preheater in only installed as on
option.
Upon pressing in activate button(③),
the activate button(③) lamp and the
pump button(④) lamp turns on, the
drive motor and the circulation pump
motor activates, and also the fan and
the fuel pump activates.
3
-
60
DEVICE CONTROL TIPS
Heater Preheater (OPTION)
OM-H228
OM-B449
REFERENCE
The heater switch type depends on
the number of heaters within the
vehicle.
WARNING
The hot water valve must be opened
before heater is turned on.
·
