- 82 -
Flywheel Housing
Tighten bolt as it is specified torque after it is
pasted sealant at the black face in the figure.
Oil Pan
1) Install an oil fan after put on oil fan gasket at
the spreaded sealant at the inveral between
cyliner block and oil fan.
Oil Cooler
Orderly assemble the oil cooler bolt after set up
the spreaded sealant at the oil cooler gasekt.
EJM2135S
EJM2136S
EJM2137S
EJM2138S
Oil Pump Bolt Torque 5.3±1.0 kg∙m
Torque 2.6±0.5 kg∙m
Torque 2.6±0.5 kg∙m
Outer Bolt 2.6±0.5 kg∙m
Inner Bolt 16.1±1 kg∙m
Coupling
Liquid gasket
(for face of cylinder
body only)
Touque
