Water Pump
Prior to put on the gasket, spread a sealant.
Cylinder Head Gasket
Be up mark "Top" and down mark "front".
Assembled Cylinder Head
Orderly and repeatly tighten after it is spreaded
engine oil at the cylinder head, as shown in
figure.
Assembly Rocker Arm Shaft
Orderly tighten the rocker arm bolt as shown in
figure.
Adjust valve clearance
Refer to section 1.5.9
EJM2146S
EJM2147S
EJM2148S
EJM2149S
EJM2150S
Standard(mm) Limit(mm)
115 116.2
102 103.2
1st step 2nd step
hexagon bolt
7.0 kg∙m 11.5+0.5
dodecaon bolt
4.0 kg∙m90�+60�(0~30�)
torque
Torque 3.1±0.5 kg∙m
Spreading Sealant
Front, Mark TOP
Front
Front
Limited value of dodecaon bolt
