Daewoo DB58 - Page 92

- 89 -
DB58TI
13
2
11
7
12
8
1
10
6
9
5
3
4
EJM2153I
<Reassembly Steps>
1. Cylinder head cove 8. Turbocharger
2. Breather 9. Turbocharge oil return pipe
3. Fan pulley 10. Turbocharge oil delivery pipe
4. Generator 11. Dipstick and guide tube
5. Fan belt 12. Intake pipe
6. Starter motor 13. Coolant hose
7. Inter cooler
