- 90 -
Cylinder Head Cover
Orderly tighten the bolt as it is shown in figure.
Fan Belt
Adjust the fan belt tension
See the item "maintenance".
Starter Motor
Tighten with the specified torque after
assemble a starter motor to fly wheel housing.
Turbocharger Mounting Flange Gasket
Carefully posit the gasket with the edged side
facing up.
Turbocharger
Tighten in the interim torborcharger nut.
Completely tighen the nut after it is assemble
oil pipe.
EJM2154S
EJM2155S
EJM2156S
EJM2157S
Bolt Torque 2.1±0.5 kg∙m
Torque 8.4 kg∙m
Torque 5.3±1 kg∙m
