-23-
Description of Each Block
4-3-2. Connectors
A. CN7, CN8 pin Spec(YEN-HO 20010WS-14 14P)
B. CN5, CN6 Pin Spec(YEON-HO 20010WS -12 12P)
CN7(AUO PANNEL)
PIN NO. OUTPUT
1 +24V
2 +24V
3 +24V
4 +24V
5 +24V
6 GND
7 GND
8 GND
9 GND
10 GND
11 DIMIMING
12 INV ON/OFF
13 N/C
14 GND
CN5, CN6(LG PANNEL)
PIN NO. OUTPUT
1 +24V
2 +24V
3 +24V
4 +24V
5 +24V
6 GND
7 GND
8 GND
9 GND
10 GND
11 DIMIMING
12 INV ON/OFF
CN8(SAMSUNG PANNEL)
PIN NO. OUTPUT
1 +24V
2 +24V
3 +24V
4 +24V
5 +24V
6 GND
7 GND
8 GND
9 GND
10 GND
11 N/C
12 INV ON/OFF
13 DIMIMING
14 N/C
