-24-
Description of Each Block
D. CN4 Pin Spec(YEON HO SMW025-09 9P)
PIN NO. OUTPUT
1 +12V
2 +12V
3 GND
4 GND
5 +5VS
6 PWR ON/OFF
7 GND
8 GND
9 +5VS
E. CN3 Pin Spec(CA3237W-300-08P)
PIN NO. OUTPUT
1 DIMIMING
2 INV ON/OFF
3 N/C
4 GND
5 GND
6 +5VS
7 +5VS
8 +12V
C. CN2 Pin Spec(YEON-HO YW025-04 4P)
PIN NO. OUTPUT
1 +29V
2 +29V
3 GND
4 GND
