AV1 AV2
AV(S)3
AV
35
NOTES:
1) When connecting a VCR the S-Video terminal provides a better
image than the Video terminal.
2) When connecting to the Video terminal, connect 3 colour AV
cables (video, left audio, right audio) to the PDP; for the SVideo
terminal, connect the Audio terminal (Left, Right) in the
same way, and connect the S-Video cable (sold separately).
3) When connecting the Video terminal and the S-Video
simultaneously, the S-Video terminal is selected. This can be
checked by the [Recall] button of the remote control.
Input Select
• Select [AV 1(Scart), AV 2(Scart) or AV 3(S-
Video)] by pressing the [AV] button of the
remote control or the “INPUT SELECT” in
keypad of the PDP unit.
• Each time you press the [AV] button, different
input modes appear.
The sequence is as follows:
3
Select the Desired Title and Function
* Select the desired title and function
by using the remote control of the VCR.
4
To Next Page
