AV1 AV2
AV(S)3
AV
37
NOTES:
1) When connecting the device, the S-Video terminal provides a
better image than the Video terminal.
2) When connecting to the Video terminal, connect 3 colour AV
cables (video, left audio, right audio) to the PDP; for the SVideo
terminal, connect the Audio terminal (Left, Right) in the
same way, and connect the S-Video cable(sold separately).
3) If connecting via component video, refer to “Watching a DVD
Image” on page 32-33.
Input Select
• Select [AV 1(Scart), AV 2(Scart) or AV 3]
by pressing the [AV] button of the
Remote Control or the “INPUT SELECT”
in keypad of the PDP unit.
• Each time you press the [AV] button,
different input modes appear.
The sequence is as follows:
3
Select Function
• Select the function by using the remote
control of camcorder or game console.
4
To Next Page
