Daewoo DWD-FT1011 - Detailed Part Code of PCB as

28
EXPLODE VIEW AND PARTS LIST
PRPSSWB100 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB101 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB102 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB103 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB104 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB105 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB106 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB107 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB108 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB109 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB110 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB111 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB400 DWD-FU101, PANA, EC,1000RPM, HOT VV, BB, VDE+1W
PRPSSWB401 DWD-FU101, PANA, EC,1000RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB402 DWD-FU101, PANA, EC,1000RPM, COLD VV, BB, VDE+1W
PRPSSWB403 DWD-FU101, PANA, EC,1000RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB404 DWD-FU121, PANA, EC,1200RPM, HOT VV, BB, VDE+1W
PRPSSWB405 DWD-FU121, PANA, EC,1200RPM, HOT VV, NON-BB, VDE+1W
PRPSSWB406 DWD-FU121, PANA, EC,1200RPM, COLD VV, BB, VDE+1W
PRPSSWB407 DWD-FU121, PANA, EC,1200RPM, COLD VV, NON-BB, VDE+1W
PRPSSWB408 DWD-FU101,PANA,NON-EC,1000RPM,HOT VV,BB, VDE+1W
PRPSSWB409 DWD-FU101,PANA,NON-EC,1000RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB410 DWD-FU101,PANA,NON-EC,1000RPM,COLD VV,BB, VDE+1W
PRPSSWB411 DWD-FU101,PANA,NON-EC,1000RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB412 DWD-FU121,PANA,NON-EC,1200RPM,HOT VV,BB, VDE+1W
PRPSSWB413 DWD-FU121,PANA,NON-EC,1200RPM,HOT VV,NON-BB, VDE+1W
PRPSSWB414 DWD-FU121,PANA,NON-EC,1200RPM,COLD VV,BB, VDE+1W
PRPSSWB415 DWD-FU121,PANA,NON-EC,1200RPM,COLD VV,NON-BB, VDE+1W
PRPSSWB112 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB113 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB114 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB115 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB120 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB121 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB122 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, BB
PRPSSWB123 DWD-F101, PANA MICOM, EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB124 DWD-F101, PANA MICOM, EC, 1200RPM, HOT V/V, BB
PRPSSWB125 DWD-F101, PANA MICOM, EC, 1200RPM, HOT V/V, NON-BB
PRPSSWB126 DWD-F101, PANA MICOM, EC, 1200RPM, COLD V/V, BB
PRPSSWB127 DWD-F101, PANA MICOM, EC, 1200RPM, COLD V/V, NON-BB
PRPSSWB128 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, BB
PRPSSWB129 DWD-F101, PANA MICOM, EC, 1000RPM, HOT V/V, NON-BB
PRPSSWB130 DWD-F102, PANA MICOM, NON-EC, 1000RPM, COLD V/V, BB
PRPSSWB131 DWD-F102, PANA MICOM, NON-EC, 1000RPM, COLD V/V, NON-BB
PRPSSWB132 DWD-F122, PANA MICOM, NON-EC, 1200RPM, HOT V/V, BB
PRPSSWB133 DWD-F122, PANA MICOM, NON-EC, 1200RPM, HOT V/V, NON-BB
PRPSSWB134 DWD-F122, PANA MICOM, NON-EC, 1200RPM, COLD V/V, BB
PRPSSWB135 DWD-F122, PANA MICOM, NON-EC, 1200RPM, COLD V/V, NON-BB
PRPSSWB136 D-FU102, AUSTRALIA, PANA, NON-EC, 1000RPM, C, B
PRPSSWB137 D-FU122, AUSTRALIA, PANA, NON-EC, 1200RPM, C, B
■ Detailed Part Code of PCB AS
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
1st PANEL
DWD-
FT1X1X
SERIES
(NON-1W)
1st PANEL
DWD-
FT1X1X
SERIES
(VDE+1W)
2nd PANEL
DWD-
FT1X2X
SERIES
(NON-1W)
1B06 PCB AS
