G424 Service Manual Base Engine Service Procedure138
6EN0569
6EN0650
DEN0053
E Lash adjuster installation
Caution: If the lash adjuster is re-used, clean the lash
adjuster.
(1) Set special tool MD998443 to prevent the lash adjuster
coming free and falling to the floor.
F Camshaft oil seal installation
(1) Apply engine oil to the lip area of the oil seal and the
camshaft front end outer diameter.
(2) Using special tool, install the camshaft oil seal.
G Semi-circular packing installation
(1) Apply sealant to the location shown in the illustration.
Specified sealant: 3M
TM
AAD Part No. 8672 or equivalent.
MD998443
MD998713
Apply sealant
To Next Page
