G424 Service Manual Charging System48
Daewoo CS-121 Series
D167411
Rated voltage..................................................12 volts
Polarity is negative ground.
Rotation is clockwise.
Output at 6500 rpm (cold).............................61 amps
Output voltage...................................14.0 L 0.5 volts
(1) Torque for battery terminal nut.......3.6 L 0.8 NIm
(32 L 7 lbIin)
(2) Torque for pulley nut...100 L 7 NIm (75 L 5 lbIft)
D187478
IDES043S
IDES044S
IDES045S
1
2
1
