022-00028AE Operation and Maintenance Manual Safety 1-5
3. WARNING FOR HANDLING ACCUMULATOR (2190-2528, 190-00099)
Accumulator
Wheel loader pilot control system is equipped with an accumulator. Accumulator will store a pressure
charge that may enable hydraulic controls to be activated for a brief period of time after engine has been
shut down. Activation of any controls may enable selected function to operate under force of gravity.
When shutting machine down, lower front attachment to ground. After engine has been shut down, turn key
to "ON" position and move joystick controls to release pressure in accumulator. Remove key.
WARNING!
Explosion hazard:
• Keep away from flame.
• Do not weld or drill.
CAUTION!
Any raised attachment will lower to ground if accumulator holds a charge.
IMPORTANT
Refer to Shop Manual for service procedures. Do not release any pilot lines until pressure within
accumulator has been released.
ACO1480L
