022-00028AE Operation and Maintenance Manual Specifications 7-1
7
SPECIFICATIONS
MEGA 200-V
GENERAL SPECIFICATIONS
NOTE:
"High torque rise"
Fuel system deliveries a control increase of fuel as the engine lugs back from rated speed.
This results in horsepower greater than rated power. The combination of increased torque
rise and maximum horsepower improves response, provides greater rimpull, more lift
COMPONENT SPECIFICATION
STD. Bucket Cap.
STD
1.8 m
3
(2.4 yd
3
)
OPT
1.9 m
3
(2.5 yd
3
)
Vehicle Weight
STD 11,000 kg (24,251 lb)
OPT 11,200 kg (24,692 lb)
Engine
Model DB58TI DB58TIS
Emission Tier I Tier II
Type Turbo, Intercooler Turbo, Charge Air Intercooler
Horsepower (see note)
140 ps @ 2,200 rpm
(138 hp @ 2,200 rpm)
(SAE J 1349 net)
Rated. 145 ps (143 hp) @ 2,200 rpm
Max. 160 ps (158 hp) @ 2,000 rpm
(Gross) (SAE J1995)
Max. Torque (see note)
57 kg•m @ 1,500 rpm
(412 ft lb @ 1,500 rpm)
(SAE J 1349 net)
64 kg•m (463 ft lb) @ 1,600 rpm
(Gross) (SAE J1995)
Transmission
Type Full Automatic Power Shift
Speeds 4 Forward, 3 Reverse
Brake Systems
Service Brakes Full Hydraulic, Separate Dual Line Wet Discs
Parking Brake Spring Applied / Oil Released on Front Axle, Dry Disc
Performance
Tr av e l S p e e d
STD 7.3 - 36 km/h (4.5 - 22.4 MPH)
OPT 8.2 - 39.5 km/h (5.1 - 24.5 MPH)
Steering Angle ± 40°
