7
-2 Specifications
022-00028AE Operation and Maintenance Manual
force, and faster cycle times. The maximum horsepower occurs at 2000 rpm when power
is needed during the working cycle.
WORKING RANGE AND DIMENSIONS
Figure 1, illustrates exterior machine dimensions and working range of machine when it is equipped with a
standard bucket.
A
(D)
B
a
b
H
I
F
C
E
G
40
O
J
APO0160L
Figure 1
