022-00028AE Operation and Maintenance Manual Operation 3-11
MACHINE TRAVEL
1. Unlatch frame lock plate between front and
rear frames before traveling. Secure lock
plate to rear frame (Figure 22).
2. Set pilot cutoff switch to "I" (UNLOCKED)
position. Raise bucket to a height of 20 -30
cm (8 - 12 in) above the ground. Tilt bucket
completely back.
WARNING!
If vehicle is moved while parking brake is engaged, serious damage to parking brake disc will
result.
Select a transmission gear that is appropriate for top speed that will be traveled. Choosing a
gear that is too high will reduce acceleration and will unnecessarily heat transmission converter
oil.
Never place transmission in "NEUTRAL" when going down a hill. Over speeding transmission
can damage transmission gears.
Never change direction of vehicle travel at high speed. Serious damage to transmission will
result.
Figure 22
HBOI110L
O
I
Figure 23
