022-00028AE Operation and Maintenance Manual Specifications 7-3
Category
Dimension
Standard Option
Overall Length (A) 7,025 mm (23' 1'')
Overall Width (B) 2,450 mm (8' 0'') 2,550 mm (8' 4'')
Overall Height (C) 3,180 mm (10' 5'') 3,260 mm (10' 8'')
Bucket Width (D) 2,450 mm (8' 0'') 2,550 mm (8' 4'')
Wheel Base (E) 2,900 mm (9' 6'')
Tread (F) 1,930 mm (6' 4'')
Ground Clearance (G) 370 mm (1' 3'') 450 mm (1' 6'')
Dump Height, to tooth (H) 2,720 mm (8' 11'') 2,730 mm (8' 11'')
Dump Distance, to Bucket Edge (I) 1,000 mm (3' 3'') 870 mm (2' 10'')
Minimum Tire Turning Radius (J) 4,950 mm (16' 3'')
Bucket Angle, Raised (a) 46°
Bucket Angle (b), Lowered (at carry) 45°
Bucket Angle (b), Lowered (on ground) 40°
Tire Size 17.5-25-12PR
20.5-25-12PR (Bias)
20.5R25 (Radial)
