7
-6 Specifications
022-00028AE Operation and Maintenance Manual
Category
Dimension
Standard Option
Overall Length (A) 7,280 mm (23' 10'') 7,280 (23' 10'')
Overall Width, without bucket (B) 2,381 mm (7' 10'')
Overall Height (C) 3,180 mm (10' 5'') 3,260 mm (10' 8'')
Bucket Width (D) 2,450 mm (8' 0.5'') 2,550 mm (8' 4'')
Wheel Base (E) 2,900 mm (9' 6.1'')
Tread (F) 1,930 mm (6' 4'')
Ground Clearance (G) 370 mm (1' 3'') 450 mm (1' 6'')
Dump Height, to tooth (H) 2,584 mm (8' 6'') 2,666 mm (8' 9'')
Dump Distance, to Bucket Edge (I) 961 mm (3' 1'') 890 mm (2' 11'')
Dump Height to Bucket Pivot (J) 3,748 mm (12' 4'') 3,828 (12' 7'')
Bucket Angle, Raised (a) 46°
Bucket Angle (b), Lowered 46°
Tire Size 17.5 x 25-12PR
20.5-25-12PR (Bias)
20.5R25 (Radial)
