2-34 Operating Controls 022-00028AE Operation and Maintenance Manual
8. REAR WIPER SWITCH
O. In this position, this switch turns
"OFF" windshield wiper mounted on
rear windshield of operator’s cab.
I. In this position, windshield washer
fluid sprays onto the rear windshield
while running the rear wiper. When
released, the switch returns to the
"O" position.
II. In this position, this switch turns "ON"
windshield wiper mounted on rear
windshield of operator’s cab.
9. ROTATING BEACON SWITCH (OPTION)
O. "OFF" position.
I. When this switch is moved to "ON"
position, it activates the warning light.
10. CUP HOLDER
Place to put beverages.
CAUTION!
The washer pump can be damaged if
it is activated while there is no fluid in
the tank. The fluid level should be
checked regularly and refilled as
necessary.
Using soap or other solvents instead
of the recommended washer fluid
may damage the wiper blades and the
paint finish. Only use the
recommended washer fluid or
equivalent.
APO0200L
O
O
I
II
Figure 59
HAOA750L
O
I
Figure 60
