41
Removing and replacing Freezer parts
* Remove screws(2ea) of Eva.
5) Disassembling R Fan AS procedure
* Remove screws(3ea) of Fixture R
Motor B.
* Remove Housing R Fan AS.
* Pull forward R Fan AS. * Separate R Fan AS.
6) Disassembling EVA AS & Accessory procedure
R Defrost Heater & Temp Fuse
Screw of EVA
R Defrost Sensor
Screw of EVA
F Defrost Heater & Temp Fuse
F Defrost Sensor
Screw of EVA
