40
* Pull forward top of F Louver.
* Remove the screw (3ea) of Fixture
F Motor A.
* Remove the screw cap (2ea) on
the F-Louver A with a flat tip driver.
Removing and replacing Freezer parts
* Strongly pull out Fan Blade and
remove. And separate Motor.
* Remove Screws (2ea) of F-Louver A.
* Separate Cover Fan Motor.
3) Disassembling F Louver AS procedure
* Disassemble housing
4) Disassembling F Fan AS procedure
* Remove the screw (1ea) of Cover
Fan Motor.
* Separate Fixture F Motor A
* Separate F Louver AS.
