Dahua DHI-ASC1204C User Manual

Installation Guide 3
2 Installation Guide
System Structure 2.1
System structure of four-door one-way access controller, door lock and reader is shown in
Figure 2-1.
Figure 2-1
Device Installation 2.2
Device installation diagram is shown in Figure 2-2 and Figure 2-3. The unit is mm.
