Quick Start Guide
11
Installation
If you do not want to install the rain cover, you could use the sticker included in the package to cover
the screw hole.
2.2.2 Villa Door Station (Single Button)
Here are examples of two model’s installation, depending on differences in model dimensions.
Model Example 1
Step 1 Open the port cover of the VTO, drill screw holes on the wall according to the dimension of
the mounting hole on the rear panel of the VTO.
Step 2 Complete the cable wiring.
Step 3 Fix the port cover or the bracket to the rear panel of the VTO with four screws.
You can use either the port cover or the bracket to mount the VTO.
Step 4 Fix the VTO on the wall with screws.
To Next Page
