Dahua DHI-VTO2311R-WP User Manual

Quick Start Guide
13
Model Example 2
Step 1 Open the port cover of the VTO, drill screw holes on the wall according to the dimension of
the mounting hole on the rear panel of the VTO.
Step 2 Complete the cable wiring.
Step 3 Fix the port cover or the bracket to the rear panel of the VTO with four screws.
You can use either the port cover or the bracket to mount the VTO.
Step 4 Fix the VTO on the wall with screws.
Dimension (mm [inch])
Installation (port cover)

Dahua DHI-VTO2311R-WP Specifications

General

Brand	Dahua
Model	DHI-VTO2311R-WP
Category	Intercom System
Language	English
